Sugar Mill Strainer Screen Filter Nozzle Of Water And Waste Water Treatmetn Plant
Water Filter Nozzle's other called:
Stainless steel filter screen, johnson screen nozzle, water and gas strainer nozzle, stainless steel filter nozzle, stainless steel filter candles, stainless steel lateral arms, wedge wire lateral pipes, wedge wire srainer, changeable filter element, header and hub laterals & hub radial laterals, water input device, water distributor, resign trans,etc.
Filter nozzle is manufactured from stainless steel material orother alloy material, which features non-clogging, high filtering efficiency and economical. It has a wide range of applications in water treatment applications. The different wedge wire sizes and slot sizes can suit different class filtration. Continuous slot design makes it high efficiency and long service life
Specification of Single Head Filter Nozzle
| Model |
D
(mm)
|
H
(mm)
|
L
(mm)
|
Slot Size
(mm)
|
Flow Area (mm2) |
| SHFN--01 |
45 |
30 |
180 |
0.18–0.50 |
380–493 |
| SHFN--02 |
45 |
40 |
190 |
0.18–0.50 |
551–690 |
| SHFN--03 |
53 |
40 |
190 |
0.18–0.50 |
453–597 |
| SHFN--04 |
53 |
50 |
200 |
0.18–0.50 |
680–710 |
| SHFN--05 |
53 |
40 |
235 |
0.18–0.50 |
800–920 |
| SHFN--06 |
57 |
40 |
190 |
0.18–0.50 |
560–670 |
| SHFN--07 |
57 |
50 |
200 |
0.18–0.50 |
780–905 |
Specification of Double Head Filter Nozzle
| Model |
D
(mm)
|
L
(mm)
|
H1
(mm)
|
H2
(mm)
|
Slot Size
(mm)
|
Flow Area (mm2) |
| WHFN-01 |
45 |
110–170 |
34 |
34 |
0.18–0.50 |
390–493 |
| WHFN-02 |
45 |
110–170 |
44 |
44 |
0.18–0.50 |
551–690 |
| WHFN-03 |
53 |
120–180 |
34 |
34 |
0.18–0.50 |
453–597 |
| WHFN-04 |
53 |
120–180 |
44 |
44 |
0.18–0.50 |
680–710 |
| WHFN-05 |
57 |
120–180 |
50 |
50 |
0.18–0.50 |
800–1000 |
| WHFN-06 |
60 |
120–180 |
50 |
50 |
0.18–0.50 |
950–1188 |
Specification of Long Handle Filter Nozzle
| Model |
Slot
(mm)
|
Outline Dimension (mm) |
Flow Area (mm2) |
| D |
H |
M |
M |
| LHFN45-30-A |
0.2–0.5 |
45 |
30 |
180 |
25 |
330 |
| LHFN45-40-B |
0.2–0.5 |
45 |
40 |
190 |
25 |
450 |
| LHFN53-40-A |
0.2–0.5 |
53 |
40 |
190 |
30 |
500 |
| LHFN53-50-B |
0.2–0.5 |
53 |
50 |
200 |
30 |
630 |
| LHFN53-40-C |
0.2–0.5 |
53 |
40 |
235 |
32 |
500 |
| LHFN57-40-A |
0.2–0.5 |
57 |
40 |
190 |
32 |
605 |
Specification of Plat Type Filter Nozzle: Double flow & single flow
| Model |
Slot
(mm)
|
Outline Dimension (mm) |
Flow Area (mm2) |
| D |
H |
M |
M |
| DFFN-82-50-A |
82 |
0.25–0.4 |
50 |
50 |
130 |
1072 |
| SFFN-82-50-B |
82 |
0.25–0.4 |
50 |
50 |
130 |
1072 |
| DFFN-53-33-A |
53 |
0.25–0.4 |
33 |
35 |
110 |
485 |
| SFFN-53-33-B |
53 |
0.25–0.4 |
33 |
35 |
110 |
485 |
Filter Nozzle BENEFITS
---Non-clogging
---High open area
---High filtering performance
---Corrosion and rust resistance
---High temperature resistance
---Economical
---Easy to install and replacement
Filter Nozzle APPLICATION
Nozzle is a key component in water treatment equipment and water installations and is widely used in power plants, petroleum, chemical, pharmaceutical, food and other industries. There are various water treatment devices equipped with wedge wire nozzles such as mechanical filtration facilities, anion-cation exchange resins, floating beds, dual chamber beds, mixed beds, gravity filters and the like
OEM service:
Please tell us the specification you need, Then we will help you to process the high quality products.
1. Material: mainly stainless steel 304, 316L, 321, Hastelloy B, C and other materials.
2. Outer diameter: 38mm, 45 mm, 53 mm, 57mm, 70mm, 82mm in usual.
3. Slot: 0.2mm-0.5mm in usual, error: + 0.03mm, can be according to customer needs.
4. Type: Female thread (G3/4", G1"), male threaded (M24 Or M32), no thread, long handle, single velocity, double velocity etc.
5. Length: 30mm, 45mm, 50mm, 100mm, 130mm, 150mm, and by customers' request.
Why choose us ?
1. We are the professional manufacturer.
2. We can give you the best quality products with competitive price.
3. Professional sales team can give you feedback within 24 hours.
4. We offer 12 months excellent after-sale service.
5. We offer customized service.
6. Our service is available twenty four seven, that is twenty four hours a day and seven days a week.
High Light Tags: oem 0.25mm stainless steel filter nozzles ; 1Tons water filter nozzles ; 316l 53mm stainless steel filter nozzles
