304 316L Stainless Steel Round Tube Slotted V Wire Screen Filter

Ss304 Pure Round Winding Slot V Wire Screen Tube, Solid Liquid Separation Filter Pipe

Pure Round Solid- Liquid Separation Winding V Wire / Wedge Wire Screen Tube

Wedge wire screen filter also be named Wound screen, Wire wrapped screen, Johnson screen, Wire screen pipe,

Well screen tube,Slotted tube.

Winding v wire / wedge wire screen tube is made of support wire and v-shaped wire around welding, support wire and V-shaped wire around resistance welding, with high welding strength, uniform gap, strong corrosion resistance, effective filtration area, good permeability, simple structure, belongs to the surface filtration form. As a filter element for various forms of automatic filters (such as automatic backwash, brush self-cleaning) for fluid filtration in various industries, the filtration accuracy is 20-800μm.

The finished products have the characteristics of high strength, high hardness, wear and corrosion resistance, uniform gap, good seepage, easy to clean and reverse cleaning.

1.  V Wire / Wedge Wire Screen Tube Application:

All kinds of stainless steel filter equipment, filter, defoamer, filter plate, filter plate and other complete set of filter equipment accessories products.

We can design and produce various specifications and models according to the needs of users, and also accept the processing of supplied materials.

2. Winding Wedge Wire Screen Tube sizes:

3.  V Wire-Wrapped Welding Screen Tubes Flow Type

• From outside to inside (FOTI)
• from inside to outside(FITO)

4.  Profile Wire an Support Wire Size of V Wire-Wrapped Welding Screen Tubes

• Profile Wire

• Profile Wire	Width	Height	Material
  10SR	0.75mm	1.5mm	304 316 316L,etc
  12SR	1.0mm	2.0mm	304 316 316L,etc
  18SR	1.5mm	2.9mm	304 316 316L,etc

• Support Wire

• Profile Wire	Width	Height	Material
  Q22	2.0mm	2.3mm	304 316 316L,etc
  Q25	2.0mm	3.0mm	304 316 316L,etc

5 .  V Wire-Wrapped Welding Screen Tubes Product Instruction

V Wire-Wrapped Welding Screen Tubes Struction: Xinlu company Slot tubes widely used in beverage / beer filtration, papermaking industry, industrial waste water treatment, oil, water desalination, etc. This slot tube is the most widely used in all kinds of filter screens.

6 .  V Wire Slot Tube Specification

• No.	Type	OD mm	ID mm	Support Wire Number	Filter Direction
  1	XLD 25.4	25.4	18.6	12	FOTI
  2	XLD 33	33	24	8	FOTI
  3	XLD 37	37	28	8	FOTI
  4	XLD 40	40	31	8 / 10	FOTI/ FITO
  5	XLD 45	45	36	10 / 12	FOTI/ FITO
  6	XLD 48	48	38	12	FOTI/ FITO
  7	XLD 60	60	51	12	FOTI/ FITO
  8	XLD 70	70	61	12 / 18	FOTI/ FITO
  9	XLD 85	85	76	18	FOTI/ FITO
  10	XLD 110	110	101	24	FOTI/ FITO
  11	XLD 120	120	111	24	FOTI/ FITO

Remarkes

1. Make Tubes with different material according to user requirements

2. Slot should be bigger than 0.025mm and less than 2500mm long, OD shoule be smaller than 220mm

 FAQ

Q1. Can I have a sample order?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A: 3-5 days for Sample preparing , 15-25 working days for mass production.

Q3. Do you have any MOQ limit for the order?

A: Low MOQ, 3pc for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?

A: Airline, sea shipping and rail transportation are all optional.

Or ship by EMS, DHL, UPS, FedEx or TNT, it takes 5-7 days to arrive.

Q5. How to proceed an order?

A: Firstly let us know your need specification or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms and places deposit for formal order.

Fourthly We arrange the production.

Q6. Is it OK to print my logo on the product?

A: Yes. Please inform us formally before our production.
