Stainless Steel Reverse Rotary Screen Drum Self Cleaning Basket Screen Filter

Stainless Steel Reverse Wedge Wire Rotary Screen Drum, Cylinder Basket For Self-Cleaning Filter

Screen Basket, CENTRIFUGE BASKET,Screen Cylinder for Self-cleaning Filter

Product Quick Detail:

1. Filter Type: Rotary Screen Drum, Screen Basket, Centrifuge Basket, Screen Cylinder

2. Material: SS304 SS316L SS321

3. Usage: Self-cleaning Filter

4. Package: Wooden case

Feiya group branch factory-Xinlu has the expertise needed to customize screen cylinders for specific makes and models of self-cleaning filters. The operation of self-cleaning filters is based on a simple concept: when pressure in the screen filter is below the permitted level, the cylinder screen allows fluid to pass while filtering out impurities. Once the pressure surpasses the limit, the flow is reversed for backwash. During this process, deposits on the screen surface are washed off and exit the filter via a discharge valve.

      Uses for the drum Screen basket

      Typical uses for the drum screen basket include mid and large size filtration equipment, including standard self-cleaning filters, rotary drum screens, rotor blade self-cleaning filters, and rotary fine-grate filters, rotary drum filters with a fine grate, rotary drum screens and other liquid / solid separation equipment. Any vibration filter, fine screening system or rotary drum filters requires the use of wedge wire cylinder screens.

      Main Specifications

      Material: stainless steel, galvanized carbon steel, carbon steel with plastic coating, or custom materials

      Slot opening size: 0.1mm – 10mm. Remember that customers can freely choose the slot opening size to suit their particular application and  operation.

      Diameter: 100-1500mm

      Length: 100-6000mm

Type 1. cylindrical baskets

Cylindrical baskets can be designed for a flow from out to in (standard construction) or from in to out (re-rolled construction). They are perfectly round and are adapted for self-cleaning filters or screw press filters. They can be cleaned with static scrappers.

Benefits

• Self cleaning surface

• High open area

• Strong construction

Features

• Dimensions adaptable to any specific needs

• Large range of constructions (wires, rods)

• All slot sizes from 25μ

• Flanges and reinforcement rings available depending on the application

Type 2 conical baskets

These conical baskets for centrifuges are widely used in the sugar and starch industries for dewatering processes (high-speed machinery).

This self-supporting structure is especially designed and engineered to

withstand the high stresses and load conditions of these processes.

Their unique design ensures:

A high mechanical strength, thus extending wear life

A precise slot opening and larger percentage of open area, thus increasing capacity

Benefits

Fast and easy installation

Long life

High resistance to abrasion, corrosion and damage by foreign objects, leading to lower maintenance

High dewatering efficiency

Features

In particularly severe conditions, different reinforcements can be dded

Special alloys and anti-abrasion coatings are also available upon request

        Wire Size Of Rotary Drum Screen Basket
