38mm Diameter 316L Stainless Steel Wire Screen 0.15mm Slot G3/ 4" Male Threaded

38mm Diameter 316L Stainless Steel Wire Screen 0.15mm Slot G3/ 4" Male Threaded
38mm Diameter 316L Stainless Steel Wire Screen 0.15mm Slot G3/ 4" Male Threaded 38mm Diameter 316L Stainless Steel Wire Screen 0.15mm Slot G3/ 4" Male Threaded 38mm Diameter 316L Stainless Steel Wire Screen 0.15mm Slot G3/ 4" Male Threaded 38mm Diameter 316L Stainless Steel Wire Screen 0.15mm Slot G3/ 4" Male Threaded 38mm Diameter 316L Stainless Steel Wire Screen 0.15mm Slot G3/ 4" Male Threaded 38mm Diameter 316L Stainless Steel Wire Screen 0.15mm Slot G3/ 4" Male Threaded

Large Image :  38mm Diameter 316L Stainless Steel Wire Screen 0.15mm Slot G3/ 4" Male Threaded

Product Details:
Place of Origin: Anping County, Hebei Province, China
Brand Name: Anping XinLu Wire Mesh Products Co.,Ltd
Certification: ISO
Model Number: XL - V Wire Screen Pipe - 09
Payment & Shipping Terms:
Minimum Order Quantity: 3pcs
Price: Negotiable
Packaging Details: wooden, pallet
Delivery Time: 5-7days
Payment Terms: T/T, L/C
Supply Ability: 100pcs / 15days

38mm Diameter 316L Stainless Steel Wire Screen 0.15mm Slot G3/ 4" Male Threaded

Description
Name: V Wire Screen Pipe, Wound Screen Diameter: 38mm
Material: Ss316L Threaded: Threaded G3/4"
Vee Wire: #63, #93, #118, #121,#130 Length: 100mm, 550mm, 750mm, 850mm
Slot: 0.15mm Selling Point: Non-magnetic, Anti-corrosion, Non-clogging,Easy Installation
High Light:

38mm Stainless Steel Wire Screen

,

316L Stainless Steel Wire Screen

,

0.15mm Slot Male Threaded Pipe

SS 316L 38mm Diameter V WireWound Screen With G3/4" Male Threaded



stainless steel vee sharped wire / wrap wire, johnson screeen, water well screen / rod based wire wrapped screen, wedge wire screen, reverse wedge wire screen, stainess steel strainer pipe, v wire slot tube, perfect roundness well screen pipe, dewatering well screen, dewatering screen panel, wedge wire grating, v wire flat panel, screen nozzle, water and gas strainer nozzle, stainless steel filter nozzle, wedge wire support grids, sieve bend plate, v wire screens, ARC screen, filter bottom nozzle, stainless steel lateral screens, wedge wire filter candles, Rotary drum screens, strainer cylinder, sand control well screen, oil well screen, rod basedc ontinuous slot screens, header and hub laterals & hub radial laterals etc.





SS 316L 38mm Diameter V WireWound Screen With G3/4" Male Threaded



V Wire Wound Screen Pipe Characteristics:



1. The application of v wire / wedge wire wound screen, so that the schroeder sieve tube gap between the formation of v-shaped opening. The design works more efficiently than other products and ensures smooth water filtration.



2. The trapezoidal wire continuous winding forms a continuous high-density uniform gap on the supporting wire in a circular arrangement, ensuring the opening area of schroeder sieve tube and no obstruction, and avoiding the high-density accumulation of sediment, providing a guarantee to improve the production efficiency and prolong the service life of the filter.



3. The winding wire and all supporting wires are connected by electric welding, durable, longer working life cycle.



4. Longitudinal arrangement of supporting wire and continuous gap form of screen tube designed according to actual demand make the product have higher compression performance.



V Wire Wound Screen Pipe Specification:



Name V Wire Wound Screen Pipe
Material Stainless steel 304, 304L, 316L and 321 etc.
Profile Wire

1.0x2.0mm 1.5x2.0mm 1.5x2.5mm 2x3mm 2.3x3.5mm 2.2x4mm 2.2x4.5mm  3x4mm  3x4.6mm etc

Support Rods 2x3mm 3x4mm 3x4.6mm 3x5mm 3x6mm 4x7mm
Round From 2.5mm to 6.0mm
Slot Size 0.025mm, 0.15mm, 0.25mm, 0.3mm ... 100mm etc
Pipe Length Max 6 meter
Pipe diameter 25mm to 1300mm
Screen Ends Plain Beveled ends, male/female threaded, flange or close up.

Package:

Plastic bubble bag packaging

Transparent plastic bag inside, woven bag outside

Wooden box

Pallet





Advantages of Wedge Wire Screen Pipe:



Non-clogging capabilities

Self supporting

High abreaction resistance

Large open area

Better sand filtration

Energy saving

Lowest possible cost

Long using life

Maximum flow capacity


Use:



water well

Juice

Beer
water supply systems
Refining & petrochemical
Filter equipment
Drum Filter
Sand control

Groundwater

Pump Filter

Motor Filter

Dewatering

Pharmaceutical

Waste water treatment





OEM service:


We can produce products according to the needs of our customers.
Material: stainless steel 304, 316L, low carbon steel
Diameter: minimum diameter 32mm, maximum diameter 1270mm
Length: single tube can be up to 6 meters in length
Gap: 0.25mm, 0.5mm, 0.7mm, 1.0mm, 1.5mm is a regular gap. We can produce gaps of 0.1-50mm
Joints: Generally, there are joints at both ends of the pipe, such as flanges, weld rings, or threads, so that the pipes can be connected to meet

---------------------------------------------------------------------------------------------------------------



Anping XinLu wire mesh products co.,ltd, it is a manufacturer and exporter of wedge wire screen products.

-----------------------------------------------------------------------------------------------------------------------------------------------



FAQ



Q0. What's the well deep can it used?

A: The common is used in the deep of 200-300m.

Water well screen pipes with the largest wire can be used for a depth of 650m.



Q1. Can I have a sample order?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.



Q2. What about the lead time?

A: 3-5 days for Sample preparing , 15-25 working days for mass production.



Q3. Do you have any MOQ limit for the order?

A: Low MOQ, 3pc for sample checking is available.



Q4. How do you ship the goods and how long does it take to arrive?

A: Airline, sea shipping and rail transportation are all optional.

Or ship by EMS, DHL, UPS, FedEx or TNT, it takes 5-7 days to arrive.



Q5. How to proceed an order?

A: Firstly let us know your need specification or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms and places deposit for formal order.

Fourthly We arrange the production.



Q6. Is it OK to print my logo on the product?

A: Yes. Please inform us formally before our production.




Johnson V Wire Screen Tube, Wedge Wire Oil Filter Tube Production Process and Pictures:

38mm Diameter 316L Stainless Steel Wire Screen 0.15mm Slot G3/ 4" Male Threaded 0

38mm Diameter 316L Stainless Steel Wire Screen 0.15mm Slot G3/ 4" Male Threaded 138mm Diameter 316L Stainless Steel Wire Screen 0.15mm Slot G3/ 4" Male Threaded 238mm Diameter 316L Stainless Steel Wire Screen 0.15mm Slot G3/ 4" Male Threaded 3

38mm Diameter 316L Stainless Steel Wire Screen 0.15mm Slot G3/ 4" Male Threaded 4
