Product Details:
|
| Product: | 1Ton Flow Rate Johnson Type Continuous Slot V Wire Wrapped Filter Screen Nozzle | Filter Type: | Johnson Screen Nozzle, Johnson Filter Nozzle, Johnson Strainer Nozzle, Wedge Wire Screen Nozzle, Water Filter Nozzle, Single Flow Strainer Nozzle, Easy Installation Screen Nozzle |
|---|---|---|---|
| Feature: | Non Clogged, Non-clogging, Smooth Surface,Easy Installation, Long Using Life | V Wire: | 1.5x2mm, 1.8x2.5mm |
| DN: | 53mm | Screen Legnth: | 45mm |
| Overalength: | 60mm | Weight: | 0.16-0.18kg/pcs |
| High Light: | Johnson Water Screen Nozzle,53mm Water Screen Nozzle,1 Ton Flow Rate Nozzle |
||
1Ton Flow Rate Johnson Type Continuous Slot V Wire Wedge Wire Wrapped Filter Screen Nozzle
Johnson Type Continuous Slot V Wire Wedge Wire Wrapped Filter Screen Nozzle also be named: Johnson screen nozzle, Johnson strainer nozzle, Johnson filter nozzle, wedge wire strainer nozzle, stainless steel filter nozzle, double flow screen nozzle, double head filter nozzle, v wire screen nozzle, water filter nozzles, water & gas strainer nozzle.
Product Quick Details:
1. Name: Johnson continuous slot v wire screen Nozzle
2. Diameter: 53mm
3. Material: SS304
4. Slot: 0.15-0.2mm
5. Flow rate: 1Ton
6. Screen Length: 45mm
7. OL: 60mm
8. Threaded: 3/4"
9. Weight: 0.16-0.18kg
10.Without nut, stainless steel washer, rubber washer
1Ton Flow Rate Johnson Type Continuous Slot V Wire Wedge Wire Wrapped Filter Screen Nozzle Characteristic:
Johnson Type Continuous Slot V Wire Wedge Wire Wrapped Filter Screen Nozzle is welded with Johnson well screen, thread pipe and steel panel through special welding process.
Johnson Type Continuous Slot V Wire Wedge Wire Wrapped Filter Screen Nozzle is the profile wedge wire screen.
Material can be 304,321,316L, titanium steel, Hastelloy etc.
Johnson Type Continuous Slot V Wire Wedge Wire Wrapped Filter Screen Nozzle Advantages:
Strong and durable
With long service life
The gap is even
No leakage of resin
No running material
High opening rate can meet the requirement of large flow
The structure is varied and meet different design requirements
Johnson Type Continuous Slot V Wire Wedge Wire Wrapped Filter Screen Nozzle Use:
Johnson Type Continuous Slot V Wire Wedge Wire Wrapped Filter Screen Nozzle is American technology.water treatment, chemical, petrochemical, pharmaceutical, biotechnology, power plant, ion exchange, yin-yang bed, mixed bed.
If you have any enquires please feel free to contact us !
Benefits: Johnson Wire Continuous Slot V Wire Wrapped Filter Screen Nozzle
Non-clogging capabilities
Self supporting
High abreaction resistance
Large open area
Better sand filtration
Energy saving
Lowest possible cost
Long using life
Maximum flow capacity
Packaging & Delivery: Johnson Wire Continuous Slot Screen Tube Filter Pipe
With plastic film or buble package with weave bag, then packed in wooden boxes or container
Plastic bubble bag packaging
Transparent plastic bag inside, woven bag outside
Wooden box
Pallet
According to your requirment.
Johnson Wire Continuous Slot V Wire Wrapped Filter Screen Nozzle Technical Data reference table:
| Model | Slot Opening Size | Dimensions | Flow area with 0.2mm slot opening (mm2) | |||
| D | L1 | L | M | |||
| FY-XL-DT-45-A | 0.2-0.5 | 45 | 25 | 90 | 25 | 280 |
| FY-XL-DT-45-B | 0.2-0.5 | 45 | 35 | 100 | 25 | 380 |
| FY-XL-DT-45-C | 0.2-0.5 | 45 | 45 | 110 | 25 | 550 |
| FY-XL-DT-45-D | 0.2-0.5 | 45 | 35 | 55 | 25 | 380 |
| FY-XL-DT-45-E | 0.2-0.5 | 45 | 45 | 65 | 25 | 550 |
| FY-XL-DT-53-A | 0.2-0.5 | 53 | 35 | 100 | 25 | 450 |
| FY-XL-DT-53-B | 0.2-0.5 | 53 | 45 | 110 | 25 | 580 |
| FY-XL-DT-53-C | 0.2-0.5 | 53 | 55 | 120 | 32 | 700 |
| FY-XL-DT-57-A | 0.2-0.5 | 57 | 35 | 100 | 32 | 530 |
| FY-XL-DT-57-B | 0.2-0.5 | 57 | 45 | 110 | 32 | 680 |
| FY-XL-DT-57-C | 0.2-0.5 | 57 | 55 | 120 | 32 | 830 |
| FY-XL-DT-70-A | 0.2-0.5 | 70 | 40 | 105 | 32 | 650 |
| FY-XL-DT-70-B | 0.2-0.5 | 70 | 55 | 115 | 32 | 810 |
If you have any inquires please feel free to contact us !
We can make any sizes according to your drawing.
FAQ
Q: Are you trading company or manufacturer?
A: We are manufacturer.
Q:To quote,what’s information needed?
A: Material, slot (mesh size), diameter/ width, length, end type / frame size, quantity, usage,etc.
Q: How long is your delivery time?
A: It is 3-5 days if the goods are in stock; for mass order, it based on the quantity.
Q: Could you provide free sample?
A: Yes, it is available for free sample, but the customers need to pay the cost of freight, which can be deducted in following order.
Q: What is your terms of payment?
A: 30% T/T as deposit,the balance before shipment.
Q:How to confirm the quality about your products?
A:During production, a few samples can be delivered to you for quality confirmation. but the customers need to pay the cost of freight.
Q: How do you make our business long-term and good relationship?
A: Effective communication; Qualified products, competitive prices, timely delivery, considerate service, etc.
---------------------------------------------------------------------------------------------------------------
Our mainly products are: stainless steel vee sharped wire / wrap wire, johnson type screeen, water well screen / rod based wire wrapped screen, wedge wire screen, reverse wedge wire screen, stainless steel strainer pipe, v wire slot tube, perfect roundness well screen pipe, dewatering well screen, dewatering screen panel, wedge wire grating, v wire flat panel, screen nozzle, water and gas strainer nozzle, stainless steel filter nozzle, wedge wire support grids, sieve bend plate, v wire screens, ARC screen, filter bottom nozzle, stainless steel lateral screens, wedge wire filter candles, Rotary drum screens, strainer cylinder, sand control well screen, oil well screen, rod based continuous slot screens, header and hub laterals & hub radial laterals etc.
