Polishing Water Filter Nozzle SS316L 55mm Legnth Wedge Wire Nozzle

Polishing Water Filter Nozzle SS316L 55mm Legnth Wedge Wire Nozzle
Polishing Water Filter Nozzle SS316L 55mm Legnth Wedge Wire Nozzle Polishing Water Filter Nozzle SS316L 55mm Legnth Wedge Wire Nozzle Polishing Water Filter Nozzle SS316L 55mm Legnth Wedge Wire Nozzle Polishing Water Filter Nozzle SS316L 55mm Legnth Wedge Wire Nozzle Polishing Water Filter Nozzle SS316L 55mm Legnth Wedge Wire Nozzle Polishing Water Filter Nozzle SS316L 55mm Legnth Wedge Wire Nozzle

Large Image :  Polishing Water Filter Nozzle SS316L 55mm Legnth Wedge Wire Nozzle

Product Details:
Place of Origin: Anping County, Hebei Province, China
Brand Name: Anping County Xinlu Wire Mesh Products Co.,Ltd
Certification: CO, Quality Inspection Report
Model Number: XL - Continuous Slot Screen - 11
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiable
Packaging Details: wooden case, pallet
Delivery Time: 8-10days
Payment Terms: T/T
Supply Ability: 150pcs / month

Polishing Water Filter Nozzle SS316L 55mm Legnth Wedge Wire Nozzle

Description
Product: Easy Installation SS316L Polishing Continuous Slot Wedge Wire Screen Nozzle Filter Type: Johnson Screen Nozzle, Johnson Filter Nozzle, Johnson Strainer Nozzle, Wedge Wire Screen Nozzle, Water Filter Nozzle, Single Flow Strainer Nozzle, Easy Installation Screen Nozzle
Feature: Polishing, Non Clogged, Non-clogging, Smooth Surface,Easy Installation, Long Using Life Wedge Wire: 1.5x2mm, 1.8x2.5mm
DN: 57mm Screen Legnth: 55mm
Overalength: 120mm Threaded: M 24 Or M32
High Light:

SS316L Water Filter Nozzle

,

Polishing Water Filter Nozzle

,

55mm Wedge Wire Nozzle


Easy Installation SS316L Polishing Johnson Continuous Slot Wedge Wire Water Filter Nozzle With M24 Male Threaded



Continuous Slot Wedge Wire Screen Nozzle also be named: Johnson screen nozzle, Johnson strainer nozzle, Johnson filter nozzle, wedge wire strainer nozzle, stainless steel filter nozzle, double flow screen nozzle, double head filter nozzle, v wire screen nozzle, water filter nozzles, water & gas strainer nozzle.



Product Quick Details:

1.  Name: Johnson continuous slot wedge wire water screen nozzle

2. Diameter: 57mm

3. Material: SS316L

4. Slot: 0.15-0.2mm

5. Flow rate: 2Ton

6. Screen Length: 55mm

7. OL: 120mm

8. Threaded:M24, or M32

9. Weight: 0.22-0.25kg

10.Withnut, stainless steel washer, rubber washer



OD 57mm Johnson Continuous Slot Wedge Wire Water Filter Nozzle With M24 Male Threaded



Johnson Continuous Slot Water Filter Nozzle is used for even flow distribution and collection in water treatment systems.

Their high open area and low entrance velocity maximize the efficiency of the filter media which increases productivity and lowers costs

.

Johnson Continuous Slot Wedge Wire Water Filter Nozzle Description:





Product Name Johnson Continuous Slot Wedge Wire Water Filter Nozzle Usage Liquid filter
Material Stainless Steel Grade 304, 321,316L, Hastelloy, in usual
Diameter 57 mm, Also can make other sizes Slot size 0.2-0.3mm
Screen Length 35 - 55 mm,or others as your request Total length 110mm
Threaded Size M24 OR M32 Profile wire size 1.5*2mm, 1.8x2.5mm
Nut 1 OR 2 PCS Support rod size 2*3mm
Gasket 1 stainless steel gasket,1 rubber gasket Type Wedge Wire Strainer Nozzle, Johnson Screen Nozzle, Filter element


Johnson Continuous Slot Wedge Wire Water Filter Nozzle Characteristic:

This wedge wire water filter nozzle is welded with

1. screen pipe

2. thread pipe

3. steel plate

4. Threaded end (is divided into female and male), some nipple with nuts and rubber washer.


Johnson Continuous Slot Water Filter Nozzle, usually with high quality stainless steel 304, 316L and other materials to ensure strong product structure and product bearing capacity.



The weight is generally 0.2-0.5kg, the volume weight is small, the appearance is exquisite.



Benefits: Johnson continuous slot wedge wire water filter nozzle

Non-clogging capabilities

Self supporting

High abreaction resistance

Large open area

Better sand filtration

Energy saving

Lowest possible cost

Long using life

Maximum flow capacity



Packaging & Delivery: Johnson continous slot wedge wire water filter nozzle

With plastic film or buble package with weave bag, then packed in wooden boxes or container

Plastic bubble bag packaging
Transparent plastic bag inside, woven bag outside
Wooden box
Pallet

According to your requirment.



Johnson continuous slot wedge wire water screen nozzle Technical Data reference table:

Model Slot Opening Size Dimensions Flow area with 0.2mm slot opening (mm2)
D L1 L M
FY-XL-DT-45-A 0.2-0.5 45 25 90 25 280
FY-XL-DT-45-B 0.2-0.5 45 35 100 25 380
FY-XL-DT-45-C 0.2-0.5 45 45 110 25 550
FY-XL-DT-45-D 0.2-0.5 45 35 55 25 380
FY-XL-DT-45-E 0.2-0.5 45 45 65 25 550
FY-XL-DT-53-A 0.2-0.5 53 35 100 25 450
FY-XL-DT-53-B 0.2-0.5 53 45 110 25 580
FY-XL-DT-53-C 0.2-0.5 53 55 120 32 700
FY-XL-DT-57-A 0.2-0.5 57 35 100 32 530
FY-XL-DT-57-B 0.2-0.5 57 45 110 32 680
FY-XL-DT-57-C 0.2-0.5 57 55 120 32 830
FY-XL-DT-70-A 0.2-0.5 70 40 105 32 650
FY-XL-DT-70-B 0.2-0.5 70 55 115 32 810



If you have any inquires please feel free to contact us !

We can make any sizes according to your drawing.





FAQ



Q: Are you trading company or manufacturer?

A: We are manufacturer.



Q:To quote,what’s information needed?

A: Material, slot (mesh size), diameter/ width, length, end type / frame size, quantity, usage,etc.



Q: How long is your delivery time?

A: It is 3-5 days if the goods are in stock; for mass order, it based on the quantity.



Q: Could you provide free sample?

A: Yes, it is available for free sample, but the customers need to pay the cost of freight, which can be deducted in following order.



Q: What is your terms of payment?

A: 30% T/T as deposit,the balance before shipment.



Q:How to confirm the quality about your products?

A:During production, a few samples can be delivered to you for quality confirmation. but the customers need to pay the cost of freight.



Q: How do you make our business long-term and good relationship?

A: Effective communication; Qualified products, competitive prices, timely delivery, considerate service, etc.
