Product Details:
|
Kewords: | Non-Magnetic Stainless Steel Water Well Screen Pipe , Wedge Wire Water Well Screen Pipe, V Wire Water Well Screen Pipe, Deep Water Well Screen Tube | Feature: | Non-clogging, Non-magnetic, Anti-rust |
---|---|---|---|
Outside Diameter: | 300mm | Profile Wire: | 2.2x3mm, 2.3x3.5mm, 2.5x4mm, 3x4.6mm |
Support Rod: | 3.0mm-5.0mm | Slot Size: | 0.1-5mm |
End Connection: | Welded Rings, Threaded Male & Female Coupling, Flange | Material: | Stainless Steel 304, 304L, 321, 316, 316L,etc |
High Light: | Stainless Steel Water Well Screen Pipe,300mm Water Well Screen Pipe,Non Magnetic Deep Well Pipe |
10-3/4Inch Non-Magnetic Stainless Steel Water Well Screen Pipe for Drilling Deep Water Filter Pump
Water Wire Screen Pipe Product introduction:
Water Wire screen pipe is also be named dewatering screen pipe, Stainless Steel Filter screen, V Wire Screen, Johnson ype screen tube, Wound screen tube, Wire wrapped screen pipe, Wedge wire screen pipe, Sand Control Slotted screen.
Water Well screen is a perfect combination of V-shaped profile wire and V-shaped rod or round support rod. The wire is welded onto the rod at each intersection point.
It is widely used throughout the world for water, oil, and gas wells, and is the dominant screen type used in the water well industry.
Advantage of Water Well Screen Pipe:
1. A continuous slot opening which significantly increases the available open area, thus providing greater access to the water bearing zone.
2. A “V”shaped profile wire which avoids clogging and ensures an uninterrupted flow.
3. A uniform and efficient well development due to the continuous slot opening.
4. Water Well screens have a strong structure and high open area, as well as accurate slot dimension.
5. Water well screens have the features of easy backwashing, last long, safety and reliability as well as low comprehensive cost.
Water Well Screen Specification list:
Size (Inch) |
O.D (mm) |
Slot (Inch) |
Length (Ft) |
Collapse Strength (PSI) |
Tensile Weight (ton) |
Wire size (mm) |
Support Rods (mm) |
4-1/2 | 114.3 | 0.040 | 10 | 395 | 6 | 2.2x3.5 | 3.0mm/22 |
4-3/4 | 120.6 | 0.040 | 10 | 395 | 6 | 2.3x3.5 | 3.8mm/22 |
6-5/8 | 168.3 | 0.040 | 10 | 252 | 8 | 2.3x3.5 | 3.8mm/32 |
8-5/8 | 219.1 | 0.010 | 10 | 399 | 10.5 | 3.0x4.6 | 3.8mm/48 |
8-5/8 | 219.1 | 0.020 | 10 | 370 | 10.5 | 3.0x4.6 | 3.8mm/48 |
8-5/8 | 219.1 | 0.040 | 10 | 323 | 10.5 | 3.0x5.0 | 3.8mm/48 |
10-3/4 | 273.1 | 0.010 | 10 | 206 | 11 | 3.0x5.0 | 3.8mm/55 |
10-3/4 | 273.1 | 0.020 | 10 | 191 | 11 | 3.0x5.0 | 3.9mm/55 |
10-3/4 | 273.1 | 0.040 | 10 | 167 | 11 | 3.0x5.0 | 4.0mm/60 |
Water Well Screen Pipe Sizes:
Diameter: 2-1/2", 3", 4-1/2", 4-3/4", 6-5/8", 8-5/8", 10-3/4", 12-3/4", 14", 16",18", 20"
Material: Low Carbon, Low Carbon Galvanized steel (LCG),Stainless Steel( 304,etc.), Duplex Stainless Steel, 904L etc.
Length: 2.9m or 5.8m to fit container, up to 6 meters.
Slot: 0.1mm, 0.2mm, 0.3mm, 0.4mm,0.5mm, 0.63mm, 0.75mm, 1.0mm, 1.5mm in usual, also can be others.
End Connection: Plain beveled ends for butt welding, male/female threaded,Flange, Closed Up etc.
Other materials available upon request.
FAQ
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: 3-5 days for Sample preparing , 15-25 working days for mass production.
Q3. Do you have any MOQ limit for the order?
A: Low MOQ, 3pcs for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: Airline, sea shipping and rail transportation are all optional.
Or ship by EMS, DHL, UPS, FedEx or TNT, it takes 5-7 days to arrive.
Q5. How to proceed an order?
A: Firstly let us know your need specification or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production.
