Activated Carbon Filter Johnson Strainer Pipe for Water Ion Exchange in Sugar Industry

Filter Johnson Strainer Pipe

Product Description:

One of the key features of our Johnson well screen pipe is its slot size, which can be customized to fit the specific needs of your well. Our slot sizes range from 0.010" to 0.10", giving you the flexibility to choose the perfect size for your application. Whether you need a fine mesh to filter out small particles or a larger opening for maximum flow, we have you covered.

Another important factor to consider when choosing a well screen pipe is the support wire. Our Johnson well screen pipe is available with support wire options of 1.8x2.5mm, 2x3mm(Q25), 2.5x4mm, 3x5mm (Q35), 3x4.6mm, and 3x6mm. These options allow you to choose the ideal combination of strength and flexibility to meet the demands of your well.

In addition to slot size and support wire, our Johnson well screen pipe is available in a range of sizes to fit your well casing. We offer sizes of 4-1/2", 6-5/8", 8-5/8", 10-3/4", 12-3/4", 14", and 16", ensuring that you can find the perfect fit for your well.

Our Johnson well screen pipe is also designed with support rods of Φ2.5-6mm, providing additional strength and stability to the screen. And with a weight range of 8-40kg/m2, you can be sure that our wire-wrapped screen pipe will provide the support and filtration you need.

Overall, our Johnson well screen pipe is the ideal solution for anyone in need of reliable, high-quality filtration for their water well. With customizable slot sizes, a range of support wire options, and a variety of sizes to choose from, you can trust our wire-wrapped screen pipe to meet your every need.

Features:

• Product Name: Water Well Screen Pipe
• Wrapped wire:
  • 0.75x1.8mm(11S)
  • 1x2mm(12S)
  • 1.5x2mm
  • 1.5x2.5mm(18S/#63)
  • 2x3mm
  • 2.2x3.5mm(#93)
  • 2.2x4.5(28SB)
  • 2.5x4mm
  • 3x4.6mm(#118)
  • 3.3x6.2mm(#130)
• Support rods: Φ2.5-6mm
• Type: Perforated/Wedge Wire/Johnson Screen/Slotted Liner/Wound Screen/Wire Wrapped
• Thickness: 5mm To 12mm
• Size: 4-1/2", 6-5/8", 8-5/8", 10-3/4", 12-3/4", 14", 16"

Our Water Well Screen Pipe is available in different types such as perforated, wedge wire, Johnson screen, slotted liner, wound screen, and wire wrapped. These screens come in various sizes ranging from 4-1/2" to 16". The wrapped wire is available in sizes such as 0.75x1.8mm(11S), 1x2mm(12S), 1.5x2mm, 1.5x2.5mm(18S/#63), 2x3mm, 2.2x3.5mm(#93), 2.2x4.5(28SB)2.5x4mm, 3x4.6mm(#118), 3.3x6.2mm(#130). The support rods have a diameter of Φ2.5-6mm. The screens have a thickness ranging from 5mm to 12mm. Our water well wound screens are designed to provide high-quality filtration in different applications.

Technical Parameters:

Applications:

Our water well screen pipe products are used in a variety of applications, including but not limited to water well drilling, oil well drilling, and geothermal drilling. They are designed to withstand low, medium, and high pressure, making them suitable for use in various environments. Our products are available in different materials, including Stainless Steel304, 321, 316L, 205,201/Carbon Steel Q235,Q195/Duplex Steel 2205/Alloy Steel, and can be customized to meet specific requirements.

The slot size of our water well screen pipes varies from 0.010" to 0.10", and the end connections include Threaded NPT, BSP, NPS/Flange/Welded Rings/Plain/Plain Beveled Ends For Butt Welding. This allows for easy installation and flexibility in different applications.

Our water well screen pipes are suitable for use in various scenarios, including but not limited to municipal water supply, irrigation, industrial water treatment, and residential water wells. They are also suitable for use in oil and gas wells, as well as geothermal wells.

At Xinlu Company, we are committed to providing our clients with high-quality water well screen pipes. We offer transparent plastic bags, woven bags, cartons, wooden boxes, and pallets for packaging, ensuring that our products are delivered safely and securely. We also offer fast delivery times, with a turnaround time of 7-10 days. Our minimum order quantity is 10pcs, and our prices range from 30-120USD/m depending on the specification. We accept T/T as our payment terms, and we have a supply ability of 500pcs/month.

Customization:

Customize your water well screen tube with Xinlu Company. We offer various models including 8-5/8" and 10-3/4". Our products are made in Anping County Xinlu Wire Mesh Products Co.,Ltd and come with FORM E, AFTA, and CO certifications.

Our minimum order quantity is 10pcs, and our price ranges from 30-120USD/m depending on the specification. We offer packaging options such as transparent plastic bags, woven bags, cartons, wooden boxes, and pallets.

With a delivery time of 7-10 days, we accept payment terms through T/T and have a monthly supply ability of 500pcs. Our products can withstand a collapse pressure of up to 300 PSI.

Choose from our selection of perforated, wedge wire, johnson screen, slotted liner, wound screen, or wire wrapped types. Our products come in a weight range of 8-40kg/m2 and materials including stainless steel 304, 321, 316L, 205, 201, carbon steel Q235, Q195, duplex steel 2205, and alloy steel.

Our products come in a length of 2.95m, 10ft, 5.85m, up to 20foot, or can be customized to fit your needs. Trust Xinlu Company for your groundwater screen tube needs.

Support and Services:

The Water Well Screen Pipe product technical support and services include:

• Expert advice on product selection and application
• Installation support and guidance
• Product troubleshooting and problem-solving
• Maintenance and repair services
• Product documentation and specifications
• Training and educational resources for customers and partners

Packing and Shipping:

Product Packaging:

The Water Well Screen Pipes are packaged in wooden crates to ensure safe shipping and handling.

Shipping:

Our company offers worldwide shipping for the Water Well Screen Pipe product. Shipping rates and delivery times may vary based on the destination and quantity ordered. Please contact us for a quote and estimated delivery time.

FAQ:

Q1: What is the brand name of the water well screen pipe?

A1: The brand name of our water well screen pipe is Xinlu Company.

Q2: What are the available models of the water well screen pipe?

A2: We offer two models of the water well screen pipe: 8-5/8" and 10-3/4".

Q3: Where is the place of origin of the water well screen pipe?

A3: The water well screen pipe is made in Anping County Xinlu Wire Mesh Products Co.,Ltd.

Q4: What are the certifications that the water well screen pipe has?

A4: The water well screen pipe has FORM E, AFTA, and CO certifications.

Q5: What is the minimum order quantity and price of the water well screen pipe?

A5: The minimum order quantity of the water well screen pipe is 10pcs, and the price ranges from 30-120USD/m, depending on the specification.

Q6: What are the packaging details and delivery time of the water well screen pipe?

A6: The water well screen pipe is packaged with transparent plastic bags, woven bags, cartons, wooden boxes, or pallets. The delivery time is 7-10 days.

Q7: What are the payment terms and supply ability of the water well screen pipe?

A7: The payment terms for the water well screen pipe is T/T, and the supply ability is 500pcs/month.
