Product Details:
|
| Product Name: | Stainless Steel Filter Nozzle, Wedge Wire Slot Nozzle, Water & Gas Strainer Nozzle, Filter Bottom Nozzle, Double Flow Screen Nozzle, Johnson Type Screen Nozzle | 1 Ton: | DN 45mm |
|---|---|---|---|
| Threaded: | M24 Or M32 Or G1" | Material: | SS304, SS316L |
| Slot: | 0.2-0.25mm | Weight: | 0.2-0.3kg/pcs |
| Type: | Single Tube Water Filter Nozzle, Double Head Johnson Filter Nozzle, Double Flow Stariner Nozzle | Uses: | Power Plants, Tanks |
| High Light: | 316L Stainless Steel Nozzles,45mm Stainless Steel Nozzles,Filter Nozzles For Water Treatment |
||
1Ton Flow Rate Single Tube Water Filter Nozzle
Water & Gas Strainer Nozzle
Product Quick Detail
1. 1Ton Flow Rate Diameter 42mm
2. End Threaded: M24
3. Length: 95mm
4. SLot: 0.2mm
5. One Piece With One nut, one stainless steel washer, one rubber washer
6. WeightL: 0.23kg/pcs
Water & Gas strainer nozzle (johnson type screen nozzles) are manufactured in accordance to customer flow requirements in almost any alloy. They can be designed for filtration or treatment systems to permit more effective use of the treatment media. Because of their non-clogging design strainer are effective in a wide rang of water treatment and other industrial applications. Common applications include under drain media retention elements or flow distributors in demineralizers and water softeners in pressure and gravity sand filters. Strainers can also be used as collectors at the bottom of the vessels by installing a number of strainers uniformly across a tray plate.The combination of high open area and a non-plugging slot design makes this nozzle /collector application pupilar.
Our Water Filter Nozzles are most commonly made with 304 or 316L stainless steel.
Water Filter Nozzle, Johnson Strainer Nozzle
Material: SS304, SS316, SS316L ,SS321
Available in a variety of standard designs or can be customer designed to meet your requirement.
| Type | Model |
Diameter D |
L | L1 | Slot | Thread |
Slot 0.2-0.25 Open area mm2 |
| FYN1 | XL45-1-A | 45 | 80 | 25 | 0.2-0.5 | M25 | 280 |
| FYN2 | XL45-1-B | 45 | 90 | 35 | 0.2-0.5 | M25 | 390 |
| FYN3 | XL45-1-C | 45 | 98 | 34 | 0.2-0.5 | M20 | 380-493 |
| FYN4 | XL45-1-D | 45 | 100 | 45 | 0.2-0.5 | M25 | 500 |
| FYN5 | XL45-1-E | 45 | 100 | 34 | 0.2-0.5 | M24 | 551-690 |
| FYN6 | XL45-1-F | 45 | 110 | 45 | 0.2-0.5 | M25 | 550 |
| FYN7 | XL45-1-G | 45 | 55 | 35 | 0.2-0.5 | M25 | 380 |
| FYN8 | XL45-1-H | 45 | 65 | 45 | 0.2-0.5 | M25 | 550 |
| FYN9 | XL53-2-A | 53 | 90 | 35 | 0.2-0.5 | M25 | 450 |
| FYN10 | XL53-2-B | 53 | 100 | 34 | 0.2-0.5 | M24 | 453-597 |
| FYN11 | XL53-2-C | 53 | 100 | 45 | 0.2-0.5 | M25 | 570 |
| FYN12 | XL53-2-D | 53 | 100 | 50 | 0.2-0.5 | M27 | 680-710 |
| FYN13 | XL53-2-E | 53 | 105 | 34 | 0.2-0.5 | M32 | 800-920 |
| FYN14 | XL53-2-F | 53 | 110 | 45 | 0.2-0.5 | M25 | 580 |
| FYN15 | XL53-2-G | 53 | 110 | 50 | 0.2-0.5 | M32 | 700 |
| FYN16 | XL53-2-H | 53 | 120 | 55 | 0.2-0.5 | M32 | 700 |
| FYN17 | XL57-3-A | 57 | 100 | 35 | 0.2-0.5 | M32 | 530 |
| FYN18 | XL57-3-B | 57 | 110 | 45 | 0.2-0.5 | M32 | 600-680 |
| FYN19 | XL57-3-C | 57 | 115 | 35 | 0.2-0.5 | M30 | 560-670 |
| FYN20 | XL57-3-D | 57 | 120 | 55 | 0.2-0.5 | M32 | 800-905 |
| FYN21 | XL60-4-A | 60 | 120 | 55 | 0.2-0.5 | G1″ | 905-1100 |
| FYN22 | XL70-5-A | 70 | 105 | 40 | 0.2-0.5 | M32 | 650 |
| FYN23 | XL70-5-B | 70 | 110 | 45 | 0.2-0.5 | M32 | 800 |
| FYN24 | XL70-5-C | 70 | 115 | 50 | 0.2-0.5 | M32 | 810 |
| FYN25 | XL70-5-D | 70 | 120 | 55 | 0.2-0.5 | M32 | 1000 |
| FYN26 | XL82-6-A | 82 | 120 | 60 | 0.2-0.5 | G2″/M42 | |
| FYN27 | XL82-6-B | 82 | 130 | 50 | 0.2-0.5 | M32 | 1170-1280 |
| FYN28 | XL108-7-A | 108 | 200 | 100 | 0.2-0.5 | G2″ | 3050-4600 |
You can choose a rubber gasket, lockable nut on the nozzle.
Note:
Fitting can be NPT thread, M20 Threaded or Rings.
Our S.SWater Filter nozzles were welded with imported S.S material. And aslo can be made by other materials. Xinlu Company nozzles have bigger filter area and have excellent strength and efficiency.
We have several kinds f nozzles with different slot opening and also can customized according to customer's requirements.
FAQ
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: 3-5 days for Sample preparing , 15-25 working days for mass production.
Q3. Do you have any MOQ limit for the order?
A: Low MOQ, 3pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: Airline, sea shipping and rail transportation are all optional.
Or ship by EMS, DHL, UPS, FedEx or TNT, it takes 5-7 days to arrive.
Q5. How to proceed an order?
A: Firstly let us know your need specification or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production.
---------------------------------------------------------------------------------------------------------------
Our mainly products are: stainless steel vee sharped wire / wrap wire, johnson type screeen, water well screen / rod based wire wrapped screen, wedge wire screen, reverse wedge wire screen, stainless steel strainer pipe, v wire slot tube, perfect roundness well screen pipe, dewatering well screen, dewatering screen panel, wedge wire grating, v wire flat panel, screen nozzle, water and gas strainer nozzle, stainless steel filter nozzle, wedge wire support grids, sieve bend plate, v wire screens, ARC screen, filter bottom nozzle, stainless steel lateral screens, wedge wire filter candles, Rotary drum screens, strainer cylinder, sand control well screen, oil well screen, rod based continuous slot screens, header and hub laterals & hub radial laterals etc.
