Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe

Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe
Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe

Large Image :  Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe

Product Details:
Place of Origin: Anping County, Hebei Province, China
Brand Name: Anping XinLu Wire Mesh Products Co.,Ltd
Certification: CO, FORM E
Model Number: XL - Wire Wrapped Screens - 05
Payment & Shipping Terms:
Minimum Order Quantity: 5pcs
Price: Negotiable
Packaging Details: carton, wooden case, pallet
Delivery Time: 8-10days
Payment Terms: T/T
Supply Ability: 150pcs / month

Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe

Description
Production Name: Wedge Wire Wrapped Screen Filter, Johnson Screen Tube, V Wire Water Well Screen, Strainer Pipe Weave Style: V Wire Or Wedge Wire Wrapped
Feature: Heat Resisting, Corrosion Resistance, Smooth Surface, Easy Installation, No Angle And No Burrs Usage: Water Supply Systems ,filter Treatment, Water Pump Drilling. Oil Well Drilling, Sand Control
Filter Rate: 80% Material: No Magnetic Ss 304
Surface Treatment: Electrolytic Polishing, Pickling And Polishing, Bright ,galvanized End Connection: Welded Rings, Threaded
High Light:

6000mm Wire Wrapped Screens

,

SS304 Wire Wrapped Screens

,

100mm Well Water Supply Pipe



Heat Resisting Water Supply Systems Wedge Wire Wrapped Screen, Johnson Screen Tube



Name: Johnson screen, Water wire screen, Water well screen, Wire warpped screen,Wedge wire screen, Johnson well screen, Johnson wire screen, Johnson screen tube, Johnson screen pipe, Johnson filter tube, Screen pipe, Screen tube, Dewatering well screen tube, stainless steel strainer pipe, oil well screen, changeable filter element, Motor Filter, Pump Filter, stainless steel filter candle, Header lateral Pipe, wedge wire strainer, perfect round screen tube, Slotted tube, Wound screen, Continuous slot screen fiter, Sand control screen,Wedge wire screen pipe, Rotary fiter drum, Oil screen.



Product Quick Detail:



1. Material: Stainless steel 304,316L,Non-magnetic SS, Low carbon galvanized,Duplex steel etc.
2. Diameter: From 29-800mm (Normal diameter is in the below table)
3. Slot: From 0.1-100mm (Normal slot 0.5mm,0.63mm,0.75mm. 1.0mm.1.5mm, Pls refer to below table)
4. Length: From 100-6000mm (Normal length is 2.9m and 5.8m, to ft container)
5. Wrap V wire:2.2*3.0mm,2.3*3.5mm,2.5*4.0mm,3*4.6mm,3*6mm,3.05*6.35mm; etc;
6. Support rod:2.3-6.0mm round wire;Also can be Vee-shaped wire.
7. Ends:Welded rings/Plain beveled ends;Male/female threaded: API STC, PT NPT, BSP, G;Flange etc.
8. Uage: Water WelI,Waste Water Treatment,Water supply systems,Coal & Mine,Food Processors & Beverage Screens,Environmental protection,Refining & Petrochemical,Architecture & Construction etc.

9. Benefits:

Non-clogging capabilities

Self supporting

High abreaction resistance

Large open area

Better sand filtration

Energy saving

Lowest possible cost

Long using life

Maximum flow capacity

Wedge Wire Wrap Screen, V Wire Johnson Screen Tube, Changeable Filter element

Wire wrap screen in stainless steel is made up of rods and wire. The rod can be round wire, triangular wire or trapezoid wire. The wire is triangular wire (V-shaped wire).

Wire wrap screen has a structure and high open area, as well as accurate slot dimension. At the same time, water well screens have heat-resisting, anti-corrosive, good machine capability, last long, safety and reliability and so on characteristics. It can be used in many kinds of medium filtering.



Advantages for Wedge Wire Wrap Screen, V Wire Johnson Screen Tube, Changeable Filter element


1. High mechanical strength to withstand greater pressure difference.

2. The homogeneous filtration gap forms a relatively homogeneous cake to facilitate backwash regeneration.

3. Wedge gap can improve backwash regeneration capacity.

4. Pressure, temperature, aging and corrosion—resistant, suitable for all kinds of fluids.

5. Metal wedged wire mesh is adopted as filter element and has the advantages, such as, high mechanical strength, high g reater pressure difference, easy cleaning, and regeneration. Al most two—dimensional filter mesh have no par— ticle packing dead space, the wedged gap can gather energy when backwashing, with good resuIt.





V-Wire Wrapped Screen Pipe Regular Specification:

sizes
(inch)
OD
(mm)
slot
(mm)
Length
(m)
Tenslile
strength
collapse
Strength

wrap wire
vee-shaped wire

(Width x height:mm)

support rod
Round wire (mm)
3-1/2 88.9 1 2.9 >22 10.2 2.3 x 3.5  3.0MMx22
4-1/2 114.3 1 2.9 >28 11.5 2.3 x 3.5 3.0MM×22
6-5/8 168.3 0.75 5.8 >40 12.8 2.3 x 3.5  3.8MM×32
6-5/8 168.3 1 5.8 >33 12.8 2.3 x 3.5  3.8MM×32
6-5/8 168.3 0.63 5.8 >83 45 3.0 x 6.0  5.OMM×32
8-5/8 219.1 1 5.8 >34 21.9 2.3 x 3.5  3.8MMx48
8-5/8 219.1 1 5.8 >50 38.2 3.0 x 4.6  4.0MMx48
8-5/8 219.1 1 5.8 >60 46 3.05 x 6.35 5.0MMx48
10-3/4 273.1 0.75 5.8 >50 9 2.5 x 4 .0 3.8MM×55
10-3/4 273.1 1 5.8 >60 39.5 3.0 x 4.6 4.5MMx55
10-3/4 273.1 1 5.8 >100 48 3.2 x 6.0  5.0MM×55
12-3/4 323.9 1 5.8 >120 37.2 3.0 x 6.0  4.0MMx56
14 355.6 1 2.9 >80 37.8 3.0 x 5.0  4.0MMx59
16 426 1 2.9 >80 37.5 3.0 x 5.0 4.OMM×64



Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe 0Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe 1

Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe 2Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe 3Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe 4Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe 5

Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe 6Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe 7Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe 8Heat Resistant Wire Wrapped Screens SS304 100mm - 6000mm Length Well Water Supply Pipe 9



FAQ



Q1. Can I have a sample order?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.



Q2. What about the lead time?

A: 3-5 days for Sample preparing , 15-25 working days for mass production.



Q3. Do you have any MOQ limit for the order?

A: Low MOQ, 3pc for sample checking is available.



Q4. How do you ship the goods and how long does it take to arrive?

A: Airline, sea shipping and rail transportation are all optional.

Or ship by EMS, DHL, UPS, FedEx or TNT, it takes 5-7 days to arrive.



Q5. How to proceed an order?

A: Firstly let us know your need specification or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms and places deposit for formal order.

Fourthly We arrange the production.



Q6. Is it OK to print my logo on the product?

A: Yes. Please inform us formally before our production.
