DN 82mm Stainless Steel Double Flow Water Filter Nozzle, Wedge Wire Screen Nozzle, Johnson strainer nozzle
Stainless steel filter screen, johnson screen nozzle, water and gas strainer nozzle, stainless steel filter nozzle, stainless steel filter candles, stainless steel lateral arms, wedge wire lateral pipes, wedge wire srainer, changeable filter element, header and hub laterals & hub radial laterals, water input device, water distributor, resign trans,etc.
Xinlu Screen Nozzles are made of vee-wire wrapped around support rods in a helix pattern to form continuous slots. Rigid construction and evenly distributed slots make the screen nozzle ideal for use as collectors and distributors in material retention and flow rate control.
We Specialize in filtration components, and are able to produce wedge wire screen nozzles with a high open area and a large flow capacity. The wedge wire nozzles are widely used in water treatment, Chemical engineering, petrochemical industries, pharmaceuticals, biochemical industries, power plants, and ion exchange systems.
Below, we’ve listed several popular models for customers to choose from.
Characteristic stainless steel water filter nozzle:
Stainless steel v / wedge - shaped wire water filter nozzle, usually with high quality stainless steel 304, 316L and other materials to ensure strong product structure and product bearing capacity.
Stainless Steel Wedge Wire Water Filter Strainer-Type DT, Water & Gas Strainer Nozzle Noraml Specification:
Filter Strainer-Type DF
Material: stainless steel 304, 316L, 321and other materials to ensure strong product structure and product bearing capacity.
Accessories: Two nuts, two rubber gaskets, one impeller, two caps, one screw M10, one filter tube
Application: Water distributor, tank, power plant
Available in a variety of standard designs or can be customer designed to meet your requirement.
Note: All the length units are in millimeter.
DF: double flow SF: single flow
| Model |
Slot Opening Size |
Dimensions |
Flow area with 0.2mm slot opening (mm2) |
| |
|
D |
L1 |
D1 |
L |
|
| FY-XL-SS-82-A |
0.25/0.4 |
82 |
50 |
50 |
130 |
1072 |
| FY-XL-SS-82-B |
0.25/0.4 |
82 |
50 |
50 |
130 |
1072 |
| FY-XL-SS-53-A |
0.25/0.4 |
53 |
33 |
36 |
110 |
485 |
| FY-XL-SS-53-B |
0.25/0.4 |
53 |
33 |
35 |
110 |
485 |
| PROFILE WIRE |
|
|
|
|
|
|
|
|
| WIDTH(mm) |
1.00 |
1.50 |
1.50 |
2.00 |
2.30 |
2.50 |
3.00 |
3.05 |
| HEIGHT(mm) |
2.00 |
2.00 |
2.50 |
3.80 |
3.50 |
4.00 |
4.60 |
6.35 |
| SUPPORT ROD |
|
|
|
|
|
ROUND |
| WIDTH(mm) |
1.80 |
2.00 |
2.50 |
3.00 |
3.00 |
Ø2.5--Ø6mm |
| HEIGHT(mm) |
2.50 |
3.00 |
4.00 |
4.60 |
6.00 |
---- |
Benefits:
Non-clogging capabilities
Self supporting
High abreaction resistance
Large open area
Better sand filtration
Energy saving
Lowest possible cost
Long using life
Maximum flow capacity
OEM service:
Please tell us the specification you need, Then we will help you to process the high quality products.
1. Material: mainly stainless steel 304, 316L, 321, Hastelloy B, C and other materials.
2. Outer diameter: 38mm, 45 mm, 53 mm, 57mm, 70mm, 82mm in usual.
3. Slot: 0.2mm-0.5mm in usual, error: + 0.03mm, can be according to customer needs.
4. Type: Female thread (G3/4", G1"), male threaded (M24 Or M32), no thread, long handle, single velocity, double velocity etc.
5. Length: 30mm, 45mm, 50mm, 100mm, 130mm, 150mm, and by customers' request.
