Easy Installation Carbon Steel Welded Pipe Anti Pressure Pump Filter Water Well Pipe

Easy Installation Carbon Steel Welded Pipe Anti Pressure Pump Filter Water Well Pipe
Easy Installation Carbon Steel Welded Pipe Anti Pressure Pump Filter Water Well Pipe Easy Installation Carbon Steel Welded Pipe Anti Pressure Pump Filter Water Well Pipe Easy Installation Carbon Steel Welded Pipe Anti Pressure Pump Filter Water Well Pipe Easy Installation Carbon Steel Welded Pipe Anti Pressure Pump Filter Water Well Pipe Easy Installation Carbon Steel Welded Pipe Anti Pressure Pump Filter Water Well Pipe Easy Installation Carbon Steel Welded Pipe Anti Pressure Pump Filter Water Well Pipe

Large Image :  Easy Installation Carbon Steel Welded Pipe Anti Pressure Pump Filter Water Well Pipe

Product Details:
Place of Origin: Anping County, Hebei Province, China
Brand Name: Anping County Xinlu Wire Mesh Products Co.,Ltd
Model Number: XL - Water Well Screen Pipe - 07
Payment & Shipping Terms:
Minimum Order Quantity: 5pcs
Price: Negotiable according to the specification
Packaging Details: wood box
Delivery Time: 5-7days
Payment Terms: T/T
Supply Ability: 30pcs/day

Easy Installation Carbon Steel Welded Pipe Anti Pressure Pump Filter Water Well Pipe

Description
Product: Stainless Steel Screen Pipe, Wedge Wire Water Well Screen Pipe, Johnson Wire Screen Pipe, Pump Filter Pipe, Wire Wrapped Screen Pipe, Oil Well Screen Pipe, Motor Filter Tube Material: Stainless Stainless 321, AISI 304, AISI 316
Advantage: Anti-Pressure, Rust Resistant, Non Clogged, High Temperature Resistance, Anti-corrosion, Usage: Pump Filter, Motor Filter, Water Or Gas Filter, Wastewater Treatment, Well Drilling
Dimensions: 88mm X 0.2mm, Or Customized Flow Type: FOTI
End Type: Welded Rings, Or Threaded Or Flange, Or End Cap Filter Type: Filter Candle, Filter Pipe, Filter Tube, Filter Element
Highlight:

Anti Pressure Carbon Steel Welded Pipe

,

Easy Installation Carbon Steel Welded Pipe

,

Pump Filter Water Well Pipe

88mm x S 0.2 mm Easy Installation Stainless Steel Wedge Wire Water Screen Pipe, Anti-Pressure Pump Filter



Oil Well Screen Pipe, Motor Filter, Pump Filter, Continuous Slot Screen Tube, Wire Wrapped Screen Tube, Stainless Steel Stariner Pipe, Wedge Wire Screen Pipe, Johnson wire Screen



Performance of  wedge wire water well screen pipe



Wedge Wire stainless/carbon steel screen pipe is a perfect combination of V-shaped wire and V-shaped rod or round rod. The wire is welded onto the rod at each intersection point.



Advantage Of Wedge Wire Screen Pipe



1. A continuous slot opening which significantly increases the available open area, thus providing greater access to the water bearing zone.


2. A V shaped profile wire which avoids clogging and ensures an uninterrupted flow.


3. A uniform and efficient well development due to the continuous slot opening.


4. wire welded screens have a strong structure and high open area, as well as accurate slot dimension.
Trapezoidal wire wire welded screens have the features of easy backwashing, last long, safety and reliability as well as low comprehensive cost.



Styles of connection: By welding or by threaded male/female coupling.



Standard length:3m/5.85m



Features of Wedeg Wire Screen Pipe



1. Screens with high open area are more suitable for the construction of high-quality water wells, oil wells and gas wells.



2. Low cost operation Screens with high open area shall favor groundwater infiltration. Abundant water shall reduce the water level’s down, thus to save energy consumption.



3. Reduce the abrasion of the pump



Under the same condition, high open area can make the speed of groundwater's entering into the screen much slower than any other filtration apparatus, which will avoid sand's entering into screen because of high pressure, thus reduce the abrasion of the pump.



4. Extend the life span of wells

Comparatively, groundwater's entering into screen with higher open area is much easier than the entering into lower open area screen. The slow water flow shall extend the life span of wells.



5. Connection method: beveled, circumferentially welded, or threaded connections



Specification of Wedge Wire Water Well Screen Pipe



SIZE

(INCH)

O.D

(MM)

SLOT

(MM)

LENGTH

(M)

COLLAPSE

STRENGTH

(BAR)

TENSILE

WEIGHT

(TON)

WRAP WIRE(WIDTH*HEIGHT)

(MM)

RODS

(MM)

3-1/2 88.9 1.0 3 >22 10.2 2.3*3.5 3.8MM/22
4-1/2 114.3 1.0 3 >28 11.5 2.3*3.5 3.8MM/22
6-5/8 168.3 0.75 5.8 >40 12.8 2.3*3.5 3.8MM/32
6-5/8 168.3 1.0 5.8 >33 12.8 2.3*3.5 3.8MM/32
6-5/8 168.3 0.63 5.8 >83 45 3.2*6.0 6.0MM*32
8-5/8 219.1 1.0 5.8 >34 21.9 2.3*3.5 3.8MM/48
8-5/8 219.1 1.0 5.8 >50 38.2 3.0*5.0 4.0MM/48
8-5/8 219.1 1.0 5.8 >60 46 3.2*6.0 5.0MM/48
10-3/4 273.1 0.75 5.8 >50 32.9 2.3*3.5 4.9MM/55
10-3/4 273.1 1.0 5.8 >60 39.5 3.0*5.0 4.9MM/55
10-3/4 273.1 1.0 5.8 >100 48 3.2*6.0 5.0MM/55
12-3/4 323.9 1.0 5.8 >120 37.2 3.0*5.0 4.0MM/50
14 355.6 1.0 3 >80 37.8 3.0*5.0 4.0MM/59



FAQ



Q1. Can I have a sample order?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.



Q2. What about the lead time?

A: 3-5 days for Sample preparing , 15-25 working days for mass production.



Q3. Do you have any MOQ limit for the order?

A: Low MOQ, 3pc for sample checking is available.



Q4. How do you ship the goods and how long does it take to arrive?

A: Airline, sea shipping and rail transportation are all optional.

Or ship by EMS, DHL, UPS, FedEx or TNT, it takes 5-7 days to arrive.



Q5. How to proceed an order?

A: Firstly let us know your need specification or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms and places deposit for formal order.

Fourthly We arrange the production.



Q6. Is it OK to print my logo on the product?

A: Yes. Please inform us formally before our production.



Q7. What's the wire?

A: Profile wire: 1.5x2mm,  Support Wire: 1.8x2.5mm / 22pcs
