Sand Control Water Well Screen Pipe 5 - 11mm Thickness Anti Corrosion Pipe

Anti-Corrosion Sand Control Well Screen Pipe With High Pressure Resistance

water well screen pipe, johnson well screeen, rod based wire wrapped screen, wedge wire screen, stainless steel strainer pipe, v wire slot tube, perfect roundness well screen pipe, dewatering well screen, stainless steel lateral screens, wedge wire filter candles, Rotary drum screens, strainer cylinder, sand control well screen, oil well screen, rod based continuous slot screens, header and hub laterals & hub radial laterals etc.

Product Advantages of Johnson Well Screen Pipe:

1.  Anti-Corrosion Sand Control Johnson Well Screen Pipe With Threaded for Groundwater

2. Selling point: High Strength, Anti-Corrosion, Easy Installation, Anti-Pressure, Rust resistant

3. Surface treatment: Pickling and polishing, Bright

4. Diameter: 2-1/2", 3", 4-1/2", 4-3/4", 6-5/8", 8-5/8", 10-3/4", 12-3/4", 14", 16",18", 20"

5. Slot size: 0.1mm, 0.2mm, 0.3mm, 0.4mm,0.5mm, 0.63mm, 0.75mm, 1.0mm, 1.5mm in usual, also can be others.

6. Length: 1m, 2m, 3m,10ft, 4m, 5m, 5.85m, 20ft (2.9m/2.95m, or 5.8m / 5.85mto fit container)

7. End connection: Plain beveled ends for butt welding, male/female threaded,Flange, Closed Up etc.

8. Material: Low Carbon, Low Carbon Galvanized steel (LCG),Stainless Steel( 304,etc.), Duplex Stainless Steel, 904L etc.

9. Well deep: v / wedge wire: 2.5x4mm Well deep: 200-300m,

v / wedge wire: 3x4.6mm Well deep: 350-450m

v / wedge wire: 3.3x6.5mm Well deep: 500-650m

Sand Control Johnson Well Screen Pipe

Screen slot design is a crucial aspect in the efficiency of production wells. Precise slot control starts with precise slot forming. Because of that, Xinlu wedge wire screen pipe is constructed by helically winding a continuous triangular shaped wire around a series of vertical support rods, ensuring the final screen slot will meets our strict quality standards.

Sand control is another crucial aspect in well management. Excess sand in pipes leads to premature pumping equipment failure. Thanks to a unique slot design, sand has a smaller chance of entering through the screen, which leads to a smaller chance of clogging or abrasions. With the wedge wire screen, a larger amount of water can easily enter the well pipe, which means increase in well productivity. Due to these factors, Feiya group branch factory-Xinlu’s water well screens are widely used in well completion, geothermal well construction, and remedial construction work.

Benefits of the Wedge Wire Screen Pipe

1. Maximum Flow Rate

The slots are arranged in a uniform pattern, allowing water to enter the screen directly from all directions of the water bearing area.

2. Excellent Sand Control Performance

Traditional perforated tubes have holes large than 1 cm, which do not keep sand out. Scratches and corrosion on the outer wrap layers leads to more sand, gravel and clay entering the well pipe, which in turn leads to clogging. However, the wedge wire screen has slot openings between 0.5mm and 1.5mm, keeping most sand and abrasive particles out.

3. Long Well Life

Each wedge wire screen undergoes anti-corrosion treatments, rendering it less prone to rust or encrustation.

4. Easy Installation

Wedge wire screens are lighter than cast iron pipes or perforated tubes, making them easier to install.

5. Standard Length

The standard length of each wedge wire screen is 3.2m. Pup joints can be added upon request.

6. Connection Method

Welded, threaded, and flanged connections are available.

Applications for the Wedge Wire Screen Pipe

This screen is applicable in vertical wells, deviated wells, directional wells, and others that require sand control.

Water Well Screen Pipe Specification list:

Other materials available upon request.

FAQ

Q1. Can I have a sample order?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A: 3-5 days for Sample preparing , 15-25 working days for mass production.

Q3. Do you have any MOQ limit for the order?

A: Low MOQ, 3pcs for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?

A: Airline, sea shipping and rail transportation are all optional.

Or ship by EMS, DHL, UPS, FedEx or TNT, it takes 5-7 days to arrive.

Q5. How to proceed an order?

A: Firstly let us know your need specification or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms and places deposit for formal order.

Fourthly We arrange the production.

Q6. Is it OK to print my logo on the product?

A: Yes. Please inform us formally before our production.
