10 Inch SS201 Johnson Water Well Slotted Wedge Wire Screen Pipe, V Wire Strainer Tube
stainless steel vee sharped wire / wrap wire, johnson screeen, water well screen / rod based wire wrapped screen, wedge wire screen, reverse wedge wire screen, stainess steel strainer pipe, v wire slot tube, perfect roundness well screen pipe, dewatering well screen, dewatering screen panel, wedge wire grating, v wire flat panel, screen nozzle, water and gas strainer nozzle, stainless steel filter nozzle, wedge wire support grids, sieve bend plate, v wire screens, ARC screen, filter bottom nozzle, stainless steel lateral screens, wedge wire filter candles, Rotary drum screens, strainer cylinder, sand control well screen, oil well screen, rod basedc ontinuous slot screens, header and hub laterals & hub radial laterals etc.
Water well slotted wedge wire screen pipe is the work-horse of the well screen industry and have been used for over 60 years for sand control.
Water well steel slotted wedge wire screen pipe can be used in both Gravel Pack and Stand Alone Screen applications.
Features of Johnson Wedge Wire Screen pipe:
integrity at every point of welding.
Tight slot control for consistent flow rates.
Stringent Quality Control measures ensure a quality product.
Weld Rings or Threaded Fittings as per customer requirements.
Multiple wire profile options to suit applications and specification.
Geological formations comprised of small, fine particles
Water wells where gravel packs will be installed
Thin aquifers, where maximum open area is required
Large- and small-diameter deep wells
Package of the water well steel slotted screen pipe:
Plastic bubble bag packaging
Transparent plastic bag inside, woven bag outside
Wooden box
Pallet
Each case is clearly marked with:
Material
Slot
Diameter
Or customized
Regular Specification:
| Wedge Wire Johnson Well Screen Pipe |
| Specification (Profile wire): |
Width(mm): 1.0 1.5 1.8 2.0 2.2 2.5 3.0 3.2 etc.
Height(mm): 2.0 2.5 3.0 3.5 4.6 5.0 6.0 etc. |
| Specification (support rods) |
Width(mm): 1.8 2.0 2.3 2.5 3.0
Height(mm): 2.5 3.0 3.5 4.0 4.6 5.0 6.0
Round: From ø2.5mm to 6.0mm round wire |
| Note: other wires and rods available upon request |
| Slot size (mm) |
0.10, 0.15, 0.20, 0.25, 0.30…… 100mm also achieved upon request. |
| Material |
Stainless steel 205, 304, 304L, 316L ,321, Low carbon, Duplex stainless steel, etc.) |
| Length |
Upto 6 meters |
| Diameter |
24-1300mm |
| Screen ends |
Plain beveled ends, male/female threaded, flange, close up. |
| Other sizes available on request. |
|
Advantage
|
Reduce energy consumption and increase water flow.
Reduce erosion of entry surfaces and increase well life.
Allow a uniform and efficient well development.
Reduce significantly potential pump damage and subsequent maintenance costs.
|
Advantages of Wedge Wire Screen Pipe:
Non-clogging capabilities
Self supporting
High abreaction resistance
Large open area
Better sand filtration
Energy saving
Lowest possible cost
Long using life
Maximum flow capacity
Use:
water well
water supply systems
Refining & petrochemical
Filter equipment
Drum Filter
Sand control
Groundwater
Pump Filter
Motor Filter
Dewatering
Characteristic:
1. Easy to leak, wear and corrosion resistance.
2. The cross section of the mesh is trapezoidal. The gap is narrow at the top and wide at the bottom.
3. It is a screen bar made of cold-rolled stainless steel wire. The support bar is welded by automatic mine screen production equipment. The screen seam is uniform, the welding quality is stable, the opening rate is high, the service life is long, and the strength is high. Rigidity and bearing capacity can be made into rigid screening and filtering devices of various shapes.
OEM service:
We can produce products according to the needs of our customers.
Material: stainless steel 304, 316L, low carbon steel
Diameter: minimum diameter 32mm, maximum diameter 1270mm
Length: single tube can be up to 6 meters in length
Gap: 0.25mm, 0.5mm, 0.7mm, 1.0mm, 1.5mm is a regular gap. We can produce gaps of 0.1-50mm
Joints: Generally, there are joints at both ends of the pipe, such as flanges, weld rings, or threads, so that the pipes can be connected to meet
---------------------------------------------------------------------------------------------------------------
FAQ
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: 3-5 days for Sample preparing , 15-25 working days for mass production.
Q3. Do you have any MOQ limit for the order?
A: Low MOQ, 3pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: Airline, sea shipping and rail transportation are all optional.
Or ship by EMS, DHL, UPS, FedEx or TNT, it takes 5-7 days to arrive.
Q5. How to proceed an order?
A: Firstly let us know your need specification or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production.
