Stainless Steel Wedge Wire 3.3 x 6.5mm Slot Filter Screen, Cylindrical Strainer
Stainless steel filter screen, Wedge Wire Screen Filter , Wedge Wire Filter Elements, Cylindrical strainer
Slotted wedge wire screen filter is produced through the method of electric resistance welding: wires with special profile are welded to supporting wires at 90 degrees angle. Its characteristic features are accurate production and precise gap sizes, which result in the ability to carry heavy loads. The slotted screen is also characterized by low possibility of blanking, perfectly smooth surface and high open surface ratio. As a result of modern technology of welding, different wires may be used, various slots in one wedge wire screen, as well as different distances between supporting wires can be created.
Product Quickly details:
Stainless steel filter screen, Wedge Wire Strainer
Screen Slot: 0.7mm
Screen OD ( has angle): 173mm
Screen Length: 241mm
Material: SUS316L
End Connection: welded ring
(OD:171,4mm x Height: 15mm
Total Length: 283mm
Profile Wire: 3.3mm x 6.5mm
Support Rod: 4.0mm
Stainless steel filter screen has high strength and high durability.
| Screen formation with wire diameter larger than the slit is possible. |
| Because the screen surface is smooth, the degree of wear is constant. |
|
The standard material is stainless steel (SUS304, 316L).
|
Therefore, Wedge Wire Screen filter feature higher strength and durability than filters such as wire mesh, perforated plates or filter cloths, and depending on the usage environment and material, they can be used almost indefinitely without replacement, reducing running costs. In addition, we are also able to produce Wedge Wire Screen using special materials such as titanium or duplex stainless steel.
Various applications of stainless steel filter screen
Wedge wire screen filter has a wide range of applications in lots of fields. They can be used as vibrating screen panels, floors, and decorative material. They have more applications in mine, coal, chemical, food and water treatment applications for filtering, screening and sizing. The different shapes and types of wedge wire screen can suit more machines, including carbon filters, desulfurizers, molecular sieves, gas sweeteners and lauter tuns.Wedge Wire Screen Filter flat screen have good filtration and dehydration in the solid- liquid separation.we can produce for you a different width.length,slit width and wedge wire size according to your requirements and the amount of filtration filter material.
| PROFILE WIRE |
|
|
|
|
|
|
|
|
| WIDTH(mm) |
1.00 |
1.50 |
1.50 |
2.00 |
2.30 |
2.50 |
3.00 |
3.05 |
| HEIGHT(mm) |
2.00 |
2.00 |
2.50 |
3.80 |
3.50 |
4.00 |
4.60 |
6.35 |
| SUPPORT ROD |
|
|
|
|
|
ROUND |
| WIDTH(mm) |
1.80 |
2.00 |
2.50 |
3.00 |
3.00 |
Ø2.5--Ø6mm |
| HEIGHT(mm) |
2.50 |
3.00 |
4.00 |
4.60 |
6.00 |
---- |
FAQ
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: 3-5 days for Sample preparing , 15-25 working days for mass production.
Q3. Do you have any MOQ limit for the order?
A: Low MOQ, 3pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: Airline, sea shipping and rail transportation are all optional.
Or ship by EMS, DHL, UPS, FedEx or TNT, it takes 5-7 days to arrive.
Q5. How to proceed an order?
A: Firstly let us know your need specification or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production.
