316 Stainless Steel Filter Screen V Shaped Johnson Wedge Wire Screens Customized

Certification
China Anping County Xinlu Wire Mesh Products Co., Ltd. certification
China Anping County Xinlu Wire Mesh Products Co., Ltd. certification
I'm Online Chat Now

316 Stainless Steel Filter Screen V Shaped Johnson Wedge Wire Screens Customized

316 Stainless Steel Filter Screen V Shaped Johnson Wedge Wire Screens Customized
316 Stainless Steel Filter Screen V Shaped Johnson Wedge Wire Screens Customized 316 Stainless Steel Filter Screen V Shaped Johnson Wedge Wire Screens Customized 316 Stainless Steel Filter Screen V Shaped Johnson Wedge Wire Screens Customized 316 Stainless Steel Filter Screen V Shaped Johnson Wedge Wire Screens Customized 316 Stainless Steel Filter Screen V Shaped Johnson Wedge Wire Screens Customized 316 Stainless Steel Filter Screen V Shaped Johnson Wedge Wire Screens Customized

Large Image :  316 Stainless Steel Filter Screen V Shaped Johnson Wedge Wire Screens Customized

Product Details:
Place of Origin: Anping County, Hebei Province, China
Brand Name: Anping County Xinlu Wire Mesh Products Co.,Ltd
Model Number: XL- stainless steel filter screen -013
Payment & Shipping Terms:
Minimum Order Quantity: 4pcs
Price: Negotiable according to the specification
Packaging Details: wood case
Delivery Time: 8-10days
Payment Terms: T/T
Supply Ability: 100pcs/20days

316 Stainless Steel Filter Screen V Shaped Johnson Wedge Wire Screens Customized

Description
Material: SS304, 316L, 321, Duplex Stainless Steel, Hastelloy Product Name: Stainless Steel 316 Johnson V Wire / Wedge Wire Filter Screen Pipe
Wedge Profile Wire: 1.5x2mm, 2x3mm,etc Diameter: 60mm, Or Customized
End Connection: Welded Rings, Threaded, Flange, Blind End Cap Slot: Min 0.05mm
Surface Treatment: Electrolytic Polishing, Pickling And Polishing Application: Filter, Filter, Mineral, Gas/oil/liquid Filtration, Industry
High Light:

316 Stainless Steel Filter Screen

,

Customized Stainless Steel Filter Screen

,

V Shaped Johnson Wedge Wire Screens

Stainless Steel 316 Johnson V Wire / Wedge Wire Filter Screen Pipe

SS316 Johnson V Wire / Wedge Wire Filter Screen Pipe



The all-welded wire-wound Johnson V Wire / Wedge Wire Filter Screen produced can be widely used in oil, gas, water well sand control and application in chemical, environmental protection and other industries. It is the most widely used filter screen used in filter materials such as various oils, water resources recycling and resin collection. Our Johnson T Wire Screen are manufactured using the world's leading full-wound welding process using a special trapezoidal (wedge) wire winding welded to a circumferential array of longitudinal support rods.



Thanks to the full-program welding, not only the strict continuous integrity of the product is ensured, but also the ideal gap size. Compared with the welding process commonly used in China, we produce filter water pipes, water caps, water distributors, resin traps and sieve plates with smooth pipe surface, no production edges and corners, no burrs, even gaps and no grease leakage. Features. All production processes are produced by professional production personnel using advanced and sophisticated professional equipment.



the economic benefits brought by the use of Johnson V Wire / Wedge Wire Filter Screen:



1. The application of the trapezoidal (wedge) wire on the filter element forms a V-shaped opening between the slits of the screen. Due to the innate advantages of this design, it can operate more efficiently than other forms of filtration products, not only ensuring the smoothness of water filtration, but also the flow rate of the wedge-shaped filter water pipe is three times that of the bridge water filter pipe in terms of work efficiency. It is 9 times the slotted water filter!



2. The structural advantages of the wound wire tube. The longitudinal support rod arrangement designed according to actual needs and the continuous gap form of the screen tube make the product have higher compression resistance. The T-shaped wire is combined with all the longitudinal support rods by electric welding, which is durable, long working life and low overall cost.


3. The Johnson V Wire / Wedge Wire Filter Screen produced by our factory has a wide gap. Customers can choose the size of the screen gap between 0.02mm-60mm to meet different application conditions.



If any interesting,pls let us talk more.

Wire Size of Johnson V Wire / Wedge Wire Filter Screen Pipe



 PROFILE WIRE
 WIDTH(mm) 1.00 1.50 1.50 2.00 2.30 2.50 3.00 3.05
 HEIGHT(mm) 2.00 2.00 2.50 3.80 3.50 4.00 4.60 6.35



 SUPPORT ROD           316 Stainless Steel Filter Screen V Shaped Johnson Wedge Wire Screens Customized 0
ROUND
 WIDTH(mm) 1.80 2.00 2.50 3.00 3.00 Ø2.5--Ø6mm
 HEIGHT(mm) 2.50 3.00 4.00 4.60 6.00 ----





Characteristic of  Johnson V Wire / Wedge Wire Filter Screen Pipe:

1. Safety.We should be sure it is not harm to the life.

2. Smooth.It cannot harm the fish.

3. Precision:For protecting in case of hurting.

4. Easy to be cleaned.Smooth surface and resistance to corrosion.

5. A long service time.Reducing your cost for filtration.



FAQ



Q1. Can I have a sample order?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.



Q2. What about the lead time?

A: 3-5 days for Sample preparing , 15-25 working days for mass production.



Q3. Do you have any MOQ limit for the order?

A: Low MOQ, 3pc for sample checking is available.



Q4. How do you ship the goods and how long does it take to arrive?

A: Airline, sea shipping and rail transportation are all optional.

Or ship by EMS, DHL, UPS, FedEx or TNT, it takes 5-7 days to arrive.



Q5. How to proceed an order?

A: Firstly let us know your need specification or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms and places deposit for formal order.

Fourthly We arrange the production.



Q6. Is it OK to print my logo on the product?

A: Yes. Please inform us formally before our production.

316 Stainless Steel Filter Screen V Shaped Johnson Wedge Wire Screens Customized 1



316 Stainless Steel Filter Screen V Shaped Johnson Wedge Wire Screens Customized 2

316 Stainless Steel Filter Screen V Shaped Johnson Wedge Wire Screens Customized 3316 Stainless Steel Filter Screen V Shaped Johnson Wedge Wire Screens Customized 4
